因为485返回的数据是ASCII的GB2312的编码,所以需要解析成UTF-8格式的方便储存。温湿度解码主要是解决表示温度的℃符号。
Imports System.IO.Ports
Public Class Form1
Private Sub comm_DataReceived(sender As Object, e As SerialDataReceivedEventArgs) Handles comm.DataReceived
Dim buf(comm.ReadBufferSize) As Byte
comm.Read(buf, 0, buf.Length)
If Array.IndexOf(buf, CByte(13)) <> -1 Then
Array.Resize(buf, Array.IndexOf(buf, CByte(13))) '定位结束回车符号\n
Else
Debug.Print("返回数据的格式错误,没有发现回车结束符!")
Exit Sub
End If
Dim s = System.Text.Encoding.GetEncoding("gb2312").GetString(buf) 'gb2312代码页面编号936
Dim tmp() As String
tmp = Split(s, ",")
Debug.Print("当前温度:" & tmp(0) & " 当前湿度:" & tmp(1).Trim & " 当前时间:" & Now)
End Sub
Private Sub Button2_Click(sender As Object, e As EventArgs) Handles Button2.Click
'打开串口接受数据
If Button2.Text = "开始调试串口" Then
comm.PortName = "COM2"
comm.Open()
Button2.Text = "暂停调试串口"
Else
comm.Close()
Button2.Text = "开始调试串口"
End If
End Sub
End Class
